ZQ-YQ-UD03 Durable Medical Ultrasound Stand with basket

Patient Monitor Trolley – Compact & Ergonomic Design

The UD03 Patient Monitor Trolley is a compact and highly mobile solution designed for modern hospital environments. Built for versatility, it features a durable round base, integrated basket, cable management hanger, and silent medical-grade wheels for smooth and quiet movement across clinical spaces.

Engineered in China with quality and functionality in mind, this all-in-one patient monitor cart supports multiple accessories and offers OEM customization options, making it easy to integrate into diverse clinical workflows.

Key features include:

  • Height-adjustable ultrasound stand for ergonomic operation

  • Secure locking system to ensure equipment stability

  • Durable, lightweight construction suitable for continuous hospital use

  • Ideal for monitoring, diagnostic imaging, and point-of-care procedures

Perfect for hospitals, clinics, and imaging centers, the UD03 trolley delivers both functionality and reliability for patient monitoring and medical equipment mobility.

Availability:
Quantity:
 Lockable ultrasound Medical Monitor Trolley with Round Base and Basket
  • ZQ-YQ-UD03

Product Description

Multi-Function Patient Monitor Trolley with Basket and Infusion Rod

The UD03 is a modern, fully-equipped patient monitor trolley designed for hospitals, clinics, and intensive care units. Featuring a round aluminum base, spacious basket, and multi-accessory integration, it ensures easy access and stability during bedside monitoring procedures.

Stable Round Base and Central Column Support

The cart’s φ600mm round base provides a low center of gravity, improving stability during movement and tilt. Made from durable medical-grade aluminum, the base ensures long-term structural integrity and load-bearing capacity of up to 15kg.

Adjustable Monitor Platform for Versatile Equipment Placement

The top shelf accommodates most standard patient monitors with a platform size of 310mm by 230mm. The reinforced column design (φ51mm) supports safe vertical mounting and aligns with hospital workflow and ergonomics.

Integrated Storage Basket and Cable Management Hook

The aluminum storage basket (330mm × 210mm × 135mm) keeps medical accessories and disposable items within reach. An integrated cable hanger ensures that power and signal lines are neatly organized to prevent tangling.

Infusion Rod and Humidifier Hook for Expanded Utility

A side-mounted φ19mm infusion rod (490mm length) allows safe hanging of IV bags or infusion equipment, while the dedicated humidifier hook adds value for respiratory applications in ICU or emergency settings.

Medical-Grade Casters with Brakes for Mobility and Control

The trolley is fitted with five 3-inch medical-grade casters, two of which are brake-enabled. These allow for smooth rolling in tight clinical spaces and secure parking during procedures. Push speed can reach up to 2m/s under full load.


Technical Specifications

Parameter

Specification

Model

UD03

Overall Dimensions

φ600mm × 890mm (H)

Base Size

φ600mm × 80mm

Column Size

φ51mm × 800mm

Monitor Platform

310mm × 230mm × 20mm

Cable Hanger

280mm × 35mm × 2mm

Storage Basket

330mm × 210mm × 135mm

Handle Size

170mm × 35mm × 45mm

Humidifier Hanger

55mm × 40mm × 16mm

Infusion Rod

φ19mm × 490mm × 200mm

Casters

5pcs × 3-inch (2 with   brakes)

Load Capacity

15 KG

Max Push Speed

2 m/s

Max Tilt Angle

15°

Net Weight

18.5 KG

Gross Weight

21 KG

Packaging Size

900mm × 570mm × 210mm



Key Product Highlights

  • Reinforced φ600mm round base for enhanced stability

  • VESA-compatible platform supports most patient monitors

  • Multi-accessory support including basket, cable hook, IV rod, humidifier hanger

  • Five medical casters with dual braking for safe  movement

  • Compact and ergonomic design for ICU, OR, and bedside use

  • OEM support available for custom branding or configurations
