ZQ-A11 Compact Ambulance Stretcher for Narrow Spaces

The ZQ-A11 is a compact stainless steel ambulance stretcher designed for patient transfer where space is limited. Its head-end loading wheels can be folded to shorten the overall length to approximately 160 cm, making the stretcher easier to move through small elevators, narrow corridors and restricted-access areas. The stretcher provides multiple height positions, a gas-spring backrest adjustment from 0° to 75° and leg adjustment from 0° to 15°. A handle-controlled folding-leg mechanism supports one-person ambulance loading, while the vehicle locking device secures the stretcher inside the ambulance. It is suitable for ambulance services, hospitals and emergency centers.

Availability:

Quantity:



Inquire Add to Basket

Model:
ZQ-A11

Product Description

Product Description

Technical Specifications

Specification	ZQ-A11
Product Type	Compact Ambulance Stretcher
Material	Stainless Steel
Surface Treatment	Powder Coated
Maximum Backrest Angle	0–75°
Leg Section Adjustment	0–15°
Height Positions	Confirm: 3 or 5
Maximum Length	198 cm
Minimum Length	Approx. 160 cm
Width	55 cm
Highest Position	198 × 55 × 91 cm
Lowest Position	198 × 55 × 40 cm
Load Capacity	≤200 kg
Net Weight	48 kg
Gross Weight	56 kg
Packing Size	203 × 64 × 43 cm
Wheel Diameter	200 mm
Wheel Type	Wide Rubber Honeycomb Wheels
Backrest Adjustment	Gas Spring
Loading	One-Person Ambulance Loading
Vehicle Locking Device	Included
Side Rails	Collapsible
IV Pole	2-Section, Optional
Oxygen Cylinder Holder	Optional

Key Features

Compact 160 cm Design: The foldable head-end wheels shorten the stretcher to approximately 160 cm, making it easier to pass through small elevators, narrow corridors and other restricted spaces.
Adjustable Patient Positioning: The stretcher provides multiple height positions, with a gas-spring adjustable backrest from 0° to 75° and leg section adjustment from 0° to 15°.
One-Person Ambulance Loading: The handle-controlled folding-leg mechanism allows one operator to push the stretcher into the ambulance.
Stainless Steel Construction: The durable stainless steel frame is powder coated for regular use in ambulance and hospital environments.
Stable 200 mm Wheels: Wide rubber honeycomb wheels provide smoother movement and shock absorption during patient transfer.
Patient Safety: Collapsible side rails，chest and knee straps, and a vehicle locking device help secure the patient and stretcher during transport.
Optional Accessories: An oxygen cylinder holder, two-section IV pole, defibrillator shelf, and ventilator shelf can be supplied according to project requirements.
